Case IH WD1504 Tier 4B (Final) Self Propelled Windrower Official Workshop Service Repair Manual
Case IH WD1504 Tier 4B (Final) Self Propelled Windrower Official Workshop Service Repair Manual
The Best PDF Manuals Online Includes : Bookmarks + Searchable Text + Index = Fast Navigation And Best Organization !
This is the COMPLETE Official Service Repair Manual for the Case IH Windrower.
This manual contains deep information about maintaining, assembly, disassembly and servicing your Windrower.
This PDF file is Bookmarked and SEARCHABLE to make what you need easy to find.
This Manual contains information and data to this model. has specs, diagrams, and actual real photo illustrations, and schemes,
which give you complete step by step operations on repair, servicing, technical maintenance & troubleshooting procedures for your machine.
this manual offers full information you need for repair your machine.
the information in this manual will enable you to find trouble and to understand how to repair and maintain your machine without going into service.
all pages are printable, so run off what you need and take it with you into the garage or workshop.
which give you complete step by step operations on repair, servicing, technical maintenance & troubleshooting procedures for your machine.
this manual offers full information you need for repair your machine.
the information in this manual will enable you to find trouble and to understand how to repair and maintain your machine without going into service.
all pages are printable, so run off what you need and take it with you into the garage or workshop.
Models & Serials Covered:
Part number 47824877
1st edition English
January 2015
Product Market Product Engine
WD1504 North America F4HFE413H*B001
Table of Contents:
Engine....................................................................................... 10
[10.001] Engine and crankcase . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.1
[10.202] Air cleaners and lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.2
[10.206] Fuel filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.3
[10.216] Fuel tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.4
[10.218] Fuel injection system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10.5
[10.254] Intake and exhaust manifolds and muffler . . . . . . . . . . .10.6
[10.310] Aftercooler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.7
[10.400] Engine cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.8
[10.414] Fan and drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10.9
[10.500] Selective Catalytic Reduction (SCR) exhaust treatment . 10.10
Transmission.............................................................................. 21
[21.900] Hydraulic pump drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21.1
Front axle system ......................................................................25
[25.310] Final drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . 25.1
Rear axle system........................................................................ 27
[27.550] Non-powered rear axle. . . . . . . . . . . . . . . . . . . . . . . . . . . . 27.1
Hydrostatic drive......................................................................... 29
[29.100] Transmission and steering hydrostatic control . . . . . . . . .29.1
[29.202] Hydrostatic transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . 29.2
[29.218] Pump and motor components. . . . . . . . . . . . . . . . . . . . . . 29.3
Brakes and controls ................................................................33
[33.110] Parking brake or parking lock . . . . . . . . . . . . . . . . . . . . 33.1
Hydraulic systems.....................................................................35
[35.000] Hydraulic systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.1
[35.100] Main lift system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35.2
[35.105] Charge pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.3
[35.304] Combination pump units . . . . . . . . . . . . . . . . . . . . . . . . . 35.4
[35.415] Header or attachment tilting system . . . . . . . . . . . . . . . 35.5
Steering..................................................................................... 41
[41.101] Steering control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41.1
Cab climate control ................................................................. 50
[50.200] Air conditioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50.1
Electrical systems ....................................................................... 55
[55.000] Electrical system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55.1
[55.019] Hydrostatic drive control system . . . . . . . . . . . . . . . . . . . . 55.2
[55.100] Harnesses and connectors. . . . . . . . . . . . . . . . . . . . . . . . . . 55.3
[55.640] Electronic modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55.4
[55.DTC] FAULT CODES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55.5
Platform, cab, bodywork, and decals ..................................... 90
[90.124] Pneumatically-adjusted operator seat. . . . . . . . . . . . . . . . 90.1
[90.150] Cab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90.2
[90.151] Cab interior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90.3
[90.154] Cab doors and hatches . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90.4
===========
Product Details :
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader
===========
